Intel® Server Board SE7500WV2

The products you are looking for are no longer manufactured by Intel. Additionally, Intel no longer provides interactive support for these products via telephone or e-mail, nor will Intel provide any future content updates or software updates to support new operating systems or improve compatibility with third party devices and software products.

THESE PRODUCT SUPPORT DOCUMENTS ARE PROVIDED FOR HISTORICAL REFERENCE ONLY AND ARE SUBJECT TO THE TERMS SET FORTH IN THE "TERMS OF USE" INFORMATION.

Information on currently available Intel products is available at www.intel.com and/or developer.intel.com


Identify your product
Product Discontinuance Announcement
Intel® will no longer provide interactive support for these products via telephone or e-mail.

Software and drivers

Technical specifications
Technical Product Specifications
Product overview, including descriptions and diagrams of the integrated features
icon SE7500WV2_TPS.PDF

Specification update
An update to the specifications contained in the Technical Product Specification
PDF Specification Update [PDF]

Installation and Use
Adapter Teaming
Intel® Server Management and Adapter Teaming are not compatible with each other. A third network adapter is necessary if you require both management and a teamed network interface.

AGP Support on Server Products
Only the Intel® Server Boards T440BX, S845WD1-E, S875WP1-E, and SE7505VB2 have an AGP slot to allow an AGP video card to be plugged in.

Authentication of "None" allowed by management utilities
Download the BMC LAN Fix Utility and the CLI AutoConfig Utility 1.05.

Clearing Processor Errors During POST
BIOS > Main > Processor Settings > Processor Retest

Configuring a RAID Array using the on-board Promise* ATA RAID Controller
When the Promise* FastTrack100™ BIOS screen appears, press CTRL+F to go to the setup screen.

DPC console reports "connection lost" with Cisco* Catalyst 4006
Enable PortFast on the switch.

Error: "Warning - FastTrak does not detect proper interrupts"
Do not press the "Pause" key while the Promise* option ROM is loading.

Error: CMOS Checksum Bad
Clear the CMOS. See the TPS for instructions.

How to set up LAN Alerts
On the managed server:
Boot to the System Setup Utility (SSU) from either the Service Partition or the System Resource CD > Platform Event Manager > Configure LAN > Enable LAN Alerts
On the client side:
Install Intel® Server Management > Start > Programs > Intel Server Management > LAN Alerts Viewer > Configure

OS install cannot detect hard drives
A single drive jumpered as slave will allow RAID array creation, but the OS install will fail. Configure single drives as master instead.

Platform Confidence Test Manual
icon Generic_BYO_PCT_Manual_3.0.pdf

Product Guide
icon Product Guide in English [WV2_PG.PDF]
icon Product Guide in Simplified Chinese [WV2_PG_SCHINESE.PDF]
icon Product Guide in Spanish [WV2_PG_SPANISH.PDF]

Quick Start User Guide
icon Quick Start User Guide [PDF]
Step #7-B of the Intel® Server Chassis SR2300 Quick Start User Guide incorrectly states that four system fans are required for dual processor configurations. Three system fans are sufficient.

Setting Up a Password for Intel® Server Management
System Setup Utility > Platform Event Manager > Configure LAN > Password

Spares/Parts List & Configuration Guide
icon Spares/Parts List & Configuration Guide

SRCMRU with firmware 2.32 not working
The SRCMR controller requires firmware 2.33.01-R01B.

System Event Log #83
The BMC logs one or two system boot events in the SEL when the BIOS finishes POST. These messages are normal.

Troubleshooting Guide
icon TS_GUIDE.PDF

Unable to access the RAID Option ROM during POST
The Matrix Storage Manager Option ROM will display only when RAID is enabled in the BIOS, at least two drives are connected to the system, and Quiet Boot is disabled in the BIOS.

Unknown devices in Device Manager
Download the INF Update Utility and the Windows* 2000 NIC Driver and the ESG-SHV Backplane Driver for Microsoft Windows*.

Viewing the System Event Log (SEL)
System Setup Utility > System Setup Screen > SEL Manager > View SEL Manager > File > Save As > Save as *.sel or *.txt.

Windows* 2000 Advanced Server recognizes only 4 GB of memory
The /PAE option must be enabled in the ARC path in the boot.ini file in order for Windows* 2000 to recognize memory above 4.0GB (e.g. multi(0)disk(0)rdisk(0)partition(2)\WINNT="Windows 2000 Advanced Server" /PAE /basevideo /sos).

Compatibility
Tested Chassis
Intel SR1300 (KCW)
Intel SR2300 (KSW or KSW480)
AIC RMC1Q2-51-SWV2
AIC RMC2Q2-SWV2
CiDesign RS2601
CCSI RC-0103X-WV2
Chenbro RM115
Chenbro RM118
Chenbro RM214

Tested Hardware and Operating Systems
Microsoft* Windows* 2000 Advanced Server, Service Pack 2
Novell Netware* 6.0
Red Hat Linux* 7.3
SuSE* Linux 8.0
icon TESTEDHW_OS.PDF

Tested Memory
icon Tested Memory List Report [PDF]

Tested Power Supplies
Delta* DPS-B480BBA 480W
Enhance* ENS00246 460W
NMB* SD237U480NSW 480W
Zippy* P2G-6460P 460W

Tested Processors
80532KC041512U
80532KC049512
80532KC056512
80532KC064512
80532KC072512
BX80532KC1800D
BX80532KC1800DU
BX80532KC2000D
BX80532KC2000DU
BX80532KC2200D
BX80532KC2200D
BX80532KC2200DU
BX80532KC2400D
BX80532KC2400D
BX80532KC2400DU
BX80532KC2600D
BX80532KC2600DU
BX80532KC2800D
BX80532KC2800DU

Technical advisories
TA615: VBAT, POST 8300 errors or RTC time loss instances
icon TA_615.PDF

TA628: BIOS Flash Chip Not Fully Write Protected
icon TA_628.PDF

TA654: Hang at POST Code 12, 13, and 15 Or During Operating System Boot
icon TA_654.PDF

TA693: Updates Needed After Intel® Server Management Uninstall
icon TA69301.PDF
